Key Features & Benefits:
Reliable & Long-Lasting Performance
- 5kWh nominal capacity, with 7.5kW peak output for handling high-demand appliances.
- 6000+ cycles at 90% DOD, ensuring a lifespan of over 10 years.
- Optimized charging and discharging for extended battery life.
Advanced Protection & Safety
- Overvoltage & undervoltage protection to prevent battery damage.
- Short-circuit protection for enhanced safety.
- Low & high temperature protection ensures operation in extreme conditions.
- Charge & discharge overcurrent protection for stable performance.
Smart Energy Management
- Dormancy function for energy conservation.
- Seamless communication with inverters via RS485, CAN, and RS232 interfaces.
- High-efficiency charging and discharging for better power utilization.
Easy Integration & Expandability
- Compatible with major solar inverters for flexible system integration.
- Compact & space-saving design, ideal for both home and commercial installations.
Technical Specifications:
- Model: Greenrich UP5000
- Nominal Capacity: 5kWh
- Rated Output Power: 7.5kW Peak
- Usable Capacity: 4.96kWh
- Cycle Life: 6000+ cycles @ 90% DOD
- Recommended Charge/Discharge Current: 43A (0.5C @ 25°C)
- Protection Features:
- Overvoltage & Undervoltage Protection
- Short-Circuit Protection
- Charge & Discharge Overcurrent Protection
- Temperature Protection (High & Low)
- Communication Interfaces: RS485 / CAN / RS232
- Size: 512 × 442 × 222.6 mm
- Weight: 51kg
What’s in the Box?
1 × Greenrich UP5000 5.2kWh Lithium-Ion Battery
1 × User Manual
1 × 3.5mm Inverter to Battery Communication Cable
Warranty & Installation Requirements:
- 10-Year Warranty for long-term reliability.
- Installation must be performed by a qualified electrical wireman or Master Electrician registered with the Department of Labour.
- A valid Electrical Certificate of Compliance (COC) must be issued upon installation.
- The system must comply with SANS 10142 regulations.
- Warranty Claims Require:
- Installation photos
- A valid COC
- Proof of installation by a qualified professional
- Failure to meet these requirements may void the warranty.
